    750W Hydraulic Crimping Tools Single Double Stage Electric Hydraulic Pump

    Ask Lasest Price
    Brand Name : Suntech
    Model Number : ZCB6-5-AB
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : L/C,T/T
    Supply Ability : 1000 PCS/Month
    Delivery Time : 7-15days
    • Product Details
    • Company Profile

    750W Hydraulic Crimping Tools Single Double Stage Electric Hydraulic Pump

    Electric Hydraulic Pump Single Or Double Stage Hydraulic Pump Tools


    About us: Suntech Power Tools, which located in the southeast China, it is the earliest origin Power Tools Leading City in China.We are making the various related cable pulling tools, and hydraulic tension and puller to support the transmission work.All can accept OEM and professionally produced per ISO 9001:2008, they are being sold to over more than 50 countries in the world,and has wined the best brand reputations. Some items like the stringing blocks,cable rollers,the cable jack stands,etc we can customized, and the Construction Safety Tools ,are not demanded the MOQ. You can freely help you out either.


    Double speed high performance pumps, built in 10000Psi pressure overflow valve, can ensure the maximum

    flow when maximum pressure.Standard of can see an oil window, observe the location of oil, with the normal operation that assures machine;

    Equipped with low noise pure aluminum alloy enclosure motor and light weight, convenient to move.


    Can choose to equip long range wire to control a switch, easy to long-distance to leave an operate

    Use the following Suggestions 200 T of hydraulic cylinder

    High and low speed two stage design is for quick oil output. Turbine oil absorption could ensure reaching max effective oil volume. Over pressure safety valve unit could avoid over pressure damage.At 700kg/cm2,automatically release.


    Electric Hydraulic Pump Feature

    1. Easy to operate and high safety

    2.Precise Machining Technique

    3. Long Life of the Machine

    4.Delicate and Beautiful Appearance Design

    5. Broader Applicable Scope

    6.Good quality and less malfunction


    Item number16153-1/A16153-2/A16153-3
    ModelZCB6-5-ABZCB6-5-A3ZCB6-5-ABC
    Typedouble-actingsingle-actingThree-acting
    Rated Output750W/1500W750W/1500W1500W
    Voltage220W/380W220W/380W220V/380V
    Rated Pressure70MPa70MPa70MPa
    Flow Ratelow pressure 2.5L/Minlw pressure 2.5L/Minlw pressure 2.5L/Min
    high pressure0.52(1.7)L/minhigh pressure0.52(1.7)L/minhigh pressure1.7L/min
    Oil Capacity8L/30L8L/30L30L
    Frequency50-60HZ50-60HZ50-60HZ
    Weight(KG)

    approx.N.W26KG

    G.W30KG

    approx.N.W25KG

    G.W29KG

    approx.N.W37KG

    G.W40KG

    Packagewooden casewooden casewooden case

    750W Hydraulic Crimping Tools Single Double Stage Electric Hydraulic Pump
